Maintenance Tables
D086/D087 2-4 SM Appendix
ARDF (D541)
Item 120K EM Remarks
Sensors C Blower brush
Platen Sheet Cover C
Damp cloth; alcohol (Replace if
required.)
White Plate C Dry or damp cloth
Drive Gear L Grease G501
Transport Roller C Damp cloth; alcohol
Exit Roller C Damp cloth; alcohol
Inverter Roller C Damp cloth; alcohol
Idle Rollers C Damp cloth; alcohol
Two-tray Paper Feed Unit (D537)
Item EM Remarks
Feed Roller C Dry cloth
Separation Roller C Dry cloth
Pick-up Belt C Dry cloth
Paper Feed Sensor C Dry cloth
Relay Sensor C Dry cloth
Relay Roller C Damp cloth
Bottom Plate Pad C Damp cloth
To Next Page
