Maintenance Tables
SM Appendix 2-1 D086/D087
Appendix:
Preventive
Maintenance
Tables
2. APPENDIX: PREVENTIVE MAINTENANCE
TABLES
2.1 MAINTENANCE TABLES
2.1.1 PREVENTIVE MAINTENANCE ITEMS
Chart: A4 (LT)/5%
Mode: 3 copies / original (prints/job)
Ratio 30%
Environment: Normal temperature and humidity
Yield may change depending on circumstances and print conditions.
Symbol keys: C: Clean, R: Replace, L: Lubricant, I: Inspect
Mainframe
Item 150K 200K 300K 450K EM Remarks
Scanner
Reflector C Optics cloth
1st/2nd/3rd mirrors C Optics cloth
Front and Rear Rails C Dry cloth
Exposure Glass C C Dry cloth; alcohol
ADF Exposure Glass C C Dry cloth; alcohol
APS Sensor C Dry cloth
PCDU
Dev. Unit–K R: 600K
Dev. Unit– C, M, Y R
Drum Unit-K, R
Drum Unit-C, M, Y R
To Next Page
