Ricoh Aficio MP C3501

Controller Options
SM 2-119 D086/D087
Installation
2.26.11 GIGABIT ETHERNET TYPE B
 Unplug the main machine power cord before you do the following procedure.
1. Remove the controller cover [A] (
x 3).
2. Pull out the controller board [B] (
x 5).
3. Remove the slot cover [A] (
x 1).
