Ricoh Aficio MP C3501 Service Manual

PM Parts Settings
D086/D087 3-2 SM
3.2 PM PARTS SETTINGS
3.2.1 BEFORE REMOVING THE OLD PM PARTS
1. Enter the SP mode.
2. Output the SMC logging data with SP5-990-004.
3. Set the following SPs to "1" before you turn the power off. Then, the machine will reset
the PM counters automatically. In the case of developer, the developer initialization will
also be done automatically.
4. Exit the SP mode.
Item SP
Developer
Black: 3902-005
Yellow: 3902-006
Cyan: 3902-007
Magenta: 3902-008
Drum Unit
Black: 3902-009
Yellow: 3902-010
Cyan: 3902-011
Magenta: 3902-012
Heating Roller and Pressure Roller (not
necessary for complete fusing units; see
below)
Heating roller: 3902-018
Pressure roller: 3902-019
Image Transfer Belt Cleaning Unit 3902-015
PTR Unit 3902-016
Toner Collection Bottle (if not full or
near-full)
3902-017
For the following units, there is a new unit detection mechanism. It is not necessary to reset
PM counters.
 PCDU
 Development unit
 Toner Collection Bottle (if full or near-full)
 Fusing unit

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
