Ricoh Aficio MP C3501 Service Manual

Controller Options
D086/D087 2-114 SM
1 Mbps: 400 m (437 yd.)
10. Press "Return to Default" to initialize the wireless LAN settings.
Press "Yes" to initialize the following settings:
 Transmission mode
 Channel
 Transmission Speed
 WEP
 SSID
 WEP Key
SP Mode and UP Mode Settings for IEEE 802.11 a/g Wireless LAN
The following SP commands and UP modes can be set for IEEE 802.11 a/g.
SP No. Name Function
5840-006 Channel MAX
Sets the maximum range of the channel settings for the
country.
5840-007 Channel MIN
Sets the minimum range of the channels settings
allowed for your country.
5840-011 WEP Key Select Used to select the WEP key (Default: 00).
UP mode Name Function
SSID Used to confirm the current SSID setting.
WEP Key
Used to confirm
the current WEP
key setting.
WEP Mode
Used to show
the maximum
length of the
string that can be
used for the
WEP Key entry.

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
