Optional Unit Combinations
D086/D087 2-6 SM
2.2.2 CONTROLLER OPTIONS
No. Options Remarks
1 Bluetooth
One from the three (I/F Slot A)
2 IEEE 802.11a/g
3 IEEE 1284
4 File Format Converter I/F Slot B
5 Gigabit Ethernet I/F Slot C
6 Security SD Card (Standard)
One from the five (SD card slot 1)
Security SD Card (Data Overwrite
Security and HDD Encryption) is in SD
card slot 1 by default. If multiple
applications are required, merge all
applications in one SD card with SP
mode. (
p.2-104 "SD Card Appli
Move")
7 PostScript 3
8 PictBridge Option
9 IPDS Unit Type C5501
10
PDF Direct (child option for
USB2.0/SD Slot)
11 Browser Unit Type E SD card slot 2 (during installation only)
12 VM Card (Standard)
SD card slot 2
This SD card is not installed in SD slot 2 by
factory default. This card should be
installed in SD slot 2 at machine
installation.
For details about the slot locations, see Controller Options.
