Ricoh Aficio MP C3501

Electrical Components
SM 5 D538
LCIT PB3110
D538
1.2.4 TRAY MOTOR
1. Rear cover (
"Tray Lift Motor")
2. Tray motor [A] (
x 1, x 2)
 When installing the tray motor, make sure that the gear of the tray motor holds the
timing belt [B].
1.2.5 MAIN BOARD
1. Rear cover (
"Tray Lift Motor" )
2. Main board [A] (All
s, x 2, snap x 2)
