Installation Requirements
SM 2-3 D086/D087
Installation
2.1.4 MACHINE DIMENSIONS
[A]: 670 mm (mainframe) + 260 mm (PFU) + 120 mm (ARDF)
[B]: 580 mm
[C]: 670 mm
[D]: 1107 mm
[E]: 535 mm
2.1.5 POWER REQUIREMENTS
Insert the plug firmly in the outlet.
Do not use an outlet extension plug or cord.
Ground the machine.
1. Input voltage level:
120 to 127 V, 60 Hz: More than 12 A
220 V to 240 V, 50 Hz/60 Hz: More than 8 A
2. Permissible voltage fluctuation: +8.66 %/ -10 %
3. Do not put things on the power cord.
