Ricoh Aficio MP C3501

Fusing
SM 4-117 D086/D087
Replacement
and
Adjustment
down.
4.11.9 STRIPPER PLATES
1. Fusing unit ( p.4-99)
2. Heating roller (
p.4-103)
3. Heating roller stripper plate [A] (spring x 2)
4. Pressure roller (
p.4-112)
5. Pressure roller stripper plate [A] (spring x 2)
