Ricoh Aficio MP C3501

1000-Sheet
Finisher
B408
DRIVE LAYOUT
SM 15 B408
4.4 DRIVE LAYOUT
1. Exit Motor
2. Upper Transport Motor
3. Lower Transport Motor
4. Shift Motor
5. Exit Guide Plate Motor
6. Lower Tray Lift Motor
7. Stack Feed-out Motor
8. Jogger Motor
9. Stapler Motor
B408D105.WMF
B408D106.WMF
B408D107.WMF
1
3
2
4
5
6
7
8
9
