Ricoh Aficio MP C3501 Service Manual

FCU
D393 22 SM
2. REPLACEMENT AND ADJUSTMENT
2.1 FCU
1. When you replace the FCU board, remove the MBU board from the old FCU board and
install it on the new FCU board.
2. Set the correct date and time with the User Tools: User Tools > System Settings >
Timer Setting > Set Date/Time.
 Do not turn off the battery switch (SW1).
 Do SP6101 to print the system parameters, and check the settings.

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
