ADF Handle Type B (D366)
SM 2-43 D086/D087
Installation
2.11 ADF HANDLE TYPE B (D366)
2.11.1 COMPONENT CHECK
Check the quantity and condition of the accessories against the following list.
No. Description Q’ty
1 Handle Unit 1
2 Holder 1
3 Stud Bracket 1
4 Securing Bracket 1
5 Handle Bracket 1
6 Hinge Stopper - Right 1
7 Hinge Stopper - Left 1
8 Spacer 1
9 Bushing: M6 1
10 Bushing: 6MM 1
11 Tapping Screw: M3 x 12 2
12 Tapping Screw (Self Binding): M3 x 12 2
13 Screw: M3 x 8 3
14 Tapping Screw: M4 x 8 4
15 Operation Decal 1
16 Stud Decal 1
To Next Page
