Ricoh Aficio MP C3501 Service Manual

IP-Fax Troubleshooting
SM 47 D545
Fax option
Type C5501
D545
Cannot send via VoIP Gateway
Check Point Action
1 LAN cable connected? Check the LAN cable connection.
2 VoIP Gateway T.38 standard? Contact the network administrator.
3 VoIP Gateway installed correctly? Contact the network administrator.
4 VoIP Gateway power switched on? Contact the network administrator.
5
Is the IP address/host name of the
specified Gateway correct?
Check the IP address/host name.
6 Number of the specified fax correct? Check the remote fax number.
7 Firewall/NAT is installed?
Cannot breach the firewall. Send by
using another method (Fax, Internet
Fax)
8 Transmission sent manually? Manual sending not supported.
9 IP address of local fax registered? Register the IP address.
10
DNS registered when host name
specified?
Contact the network administrator.
11 Remote fax a G3 fax? Check that the remote fax is a G3 fax.
12 G3 fax is connected to VoIP gateway? Check that G3 fax is connected.
13 Remote G3 fax turned on? Check that G3 fax is switched on.
14 Network bandwidth too narrow?
Request the network administrator to
increase the bandwidth.
Raise the network delay level.
IPFAX SW 01 Bit 0 to 3
IP-Fax bandwidth is the same as the
DCS speed. Set IP-Fax SW00 Bit 6 to
1.

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
