Fax Unit (D393)
SM 1 D393
Fax Option
Type C5000
(D393)
1. INSTALLATION PROCEDURE
1.1 FAX UNIT (D393)
1.1.1 COMPONENT CHECK
Check the quantity and condition of the components against the following list.
No. Description Q'ty
1 FCU I/F Board 1
2 FCU 1
3 FCU I/F Board Bracket 1
4 Support Bracket 1
5 Speaker 1
6 Modular Bracket 1
7 Handset Bracket (NA only) 2
8 Handset Support Bracket (NA only) 1
9 Screw: M3x6 (NA only) 2
10 Telephone Cable (NA only) 1
11 Multi-Language Decals
1 (Excluding NA)/ 2
(EU)
12 Harness: TEL and LINE 2
13 G3 Decal 1
14 Serial Number Decal 1
15 FCC Decal (NA only) 1
16 Ferrite Core 1 (EU) or 2 (NA)
To Next Page
