Input and Output Check
D086/D087 3-402 SM Appendix
5803 55 Paper Exit Fan:Lock Normal Lock
5803 56 Fusing Coil Fan: Lock Normal Lock
5803 57 IH Power Supply Cooling Fan: Lock Normal Lock
5803 58 Airflow Fan: Middle 1: Lock Not used
5803 59 Airflow Fan: Middle 2: Lock Not used
5803 60 ITB Contact Motor Position Not contact Contact
5803 61
Paper Transfer Contact Motor
Position
Not contact Contact
5803 62 Toner Relay Motor: Lock Normal Lock
5803 63 ITB Drive Motor: Lock Normal Lock
5803 64
K Drum/Development Drive Motor:
Lock
Normal Lock
5803 65
M Drum/Development Drive Motor:
Lock
Normal Lock
5803 66
C Drum/Development Drive Motor:
Lock
Normal Lock
5803 67
Y Drum/Development Drive Motor:
Lock
Normal Lock
5803 68 Fusing Exit Motor:Lock Normal Lock
5803 80 HVPS:TTS:SC Detection SC detected No SC
5803 81 HVPS:CB:SC Detection SC detected No SC
5803 82 HVPS:D:SC Detection SC detected No SC
5803 83
Fusing Destination Detection: DOM
(Dom)
Set Not set
