Input and Output Check
D086/D087 3-410 SM Appendix
1000-Sheet Finisher (B408)
6139 Bit Description
Reading
0 1
6139 1 Entrance Sensor Paper detected
Paper not
detected
6139 2
Shift Exit Sensor
(Lower Tray Exit Sensor)
Paper not
detected
Paper detected
6139 3
Staple Entrance Sensor
(Stapler Tray Entrance Sensor)
Paper detected
Paper not
detected
6139 4
Staple Moving HP Sensor
(Stapler HP Sensor)
Not home position Home position
6139 5
Jogger HP Sensor
(Jogger Fence HP Sensor)
Not home position Home position
6139 6 Stack Feed-out Belt HP Sensor Home position
Not home
position
6139 7 Staple Tray Paper Sensor
Paper not
detected
Paper detected
6139 8
Staple Rotation Sensor
(Staple Rotation HP Sensor)
Not home position Home position
6139 9 Staple Sensor Staple detected
Staple not
detected
6139 10 Staple READY Detection Staple detected
Staple not
detected
6139 11
Exit Guide Plate HP
(Exit Guide Plate HP Sensor)
Not home position Home position
6139 12 Shift HP Sensor Not home position Home position
6139 13
Paper Sensor
(Stack Height Sensor)
Output tray not
detected
Output tray
detected
