Input and Output Check
D086/D087 3-412 SM Appendix
500-Sheet Finisher (D372)
6145 Description
Reading
0 1
6145 1 Entrance Sensor Paper detected
Paper not
detected
6145 2 Hitroll HP Sensor
Paper not
detected
Paper detected
6145 3
Front Jogger HP Sensor
(Front Jogger Fence HP Sensor)
Home position Not home position
6145 4
Rear Jogger HP Sensor
(Rear Jogger Fence HP Sensor)
Home position Not home position
6145 5 Staple Tray Paper Sensor Paper detected
Paper not
detected
6145 6 Staple Moving HP Sensor Not HP HP
6145 7 Stack Feed-out Belt HP Not HP HP
6145 8 Shift Tray Paper Sensor Paper detected
Paper not
detected
6145 9 Upper Cover Sensor HP Not HP
6145 10 Staple Rotation Sensor HP Not HP
6145 11 Staple Near End HP Not HP
6145 12 Self Priming HP Not HP
6145 13 Shift Tray Limit Sensor Not full Full
