ELECTRICAL COMPONENT LAYOUT
B408 12 SM
22. Tray Junction Gate Solenoid
23. Lower Tray Lift Motor
24. Lower Tray Lower Limit Sensor
25. Stapler Motor
26. Jogger Fence Motor
27. Stack Feed-out Motor
28. Main Board
29. Lower Transport Motor
30. Stapler Junction Gate Solenoid
31. Exit Motor
32. Upper Transport Motor
B408D104.WMF
23
24
25
26
27
28
22
29
30
31
32
To Next Page
