Component Layout
SM 39 B793
B793
Booklet
Finisher
Item No. Purpose
Punch HP
Sensor
50 Detects when the hole-punch firing mechanism is at home position
Paper
Position
Slide HP
Sensor
53
Detects when the mechanism that measures the paper position in the
punch unit is at home position
Paper
Position
Sensor
54
Detects the side edge of the paper, to tell the machine where to put
the punch holes.
Punch
Movement
HP Sensor
55
Detects when the side-to-side motion of the punch unit is at home
position.
Punch
Hopper Full
Sensor
56
Detects when the punch hopper is full. Also checks if the hopper is
installed correctly.
To Next Page
