Booklet Tray
SM 47 B793
B793
Booklet
Finisher
Condition Front Sensor Rear Sensor
Ready ON OFF
Full 1 ON ON
Full 2 OFF ON
Full 3 (or booklet tray not
installed)
OFF OFF
In the tables below:
"Sht" denotes "sheets in a stack".
"Cnt" denotes "Count" (see below for an explanation).
After a booklet is feed out, the fold roller motor stops the exit roller. The machine then
monitors the tray full sensors every feed-out of a paper stack. The machine checks a
certain condition, based on the size of the paper and the number of sheets in the booklet.
Two examples are shown below the table. Tell the operators that the number of sheets that
the lower tray can hold will vary greatly.
- Lower Tray Full Condition Tables -
A3 (DLT)
Sheet 1 2 3 4 5 6 7 8 9 10
Full 1
15
Cnt
- - - - - - - - -
Full 2 - 3 Cnt
11
Cnt
- - - - - - -
Full 3 - - -
16
Cnt
12
Cnt
2 Cnt 3 Cnt 5 Cnt 6 Cnt 7 Cnt
A4 (LT)
Sheet 1 2 3 4 5 6 7 8 9 10
Full 1
15
Cnt
- - - - - - - - -
Full 2 - 8 Cnt
16
Cnt
19
Cnt
5 Cnt 2 Cnt 2 Cnt 2 Cnt 3 Cnt 4 Cnt
Full 3 - - - - - - - - - -
