Ricoh Aficio MP C3501 Service Manual

Error Codes
D393 26 SM
Code Meaning Suggested Cause/Action
Cross reference
See error code 0-08.
0-20
Facsimile data not
received within 6 s of
retraining
 Check the line connection.
 Replace the FCU.
 Check for line problems.
 Try calling another fax machine.
 Try adjusting the reconstruction time for the
first line and/or rx cable equalizer setting.
Cross reference
Reconstruction time - G3 Switch 0A, bit 6
Rx cable equalizer - G3 Switch 07 (PSTN)
0-21
EOL signal (end-of-line)
from the other end not
received within 5 s of the
previous EOL signal
 Check the connections between the FCU and
line.
 Check for line noise or other line problems.
 Replace the FCU.
 The remote machine may be defective or may
have disconnected.
Cross reference
Maximum interval between EOLs and between
ECM frames - G3 Bit Switch 0A, bit 4
0-22
The signal from the other
end was interrupted for
more than the acceptable
modem carrier drop time
(default: 200 ms)
 Check the line connection.
 Replace the FCU.
 Defective remote terminal.
 Check for line noise or other line problems.
 Try adjusting the acceptable modem carrier
drop time.
Cross reference
Acceptable modem carrier drop time - G3 Switch
0A, bits 0 and 1
0-23
Too many errors during
reception
 Check the line connection.
 Replace the FCU.
 Defective remote terminal

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
