Ricoh Aficio MP C3501

Service Tables
D393 58 SM
4.2.2 SP2-XXX (RAM DATA)
2
Mode No. Function
RAM Read/Write
101
001
Change RAM data for the fax board directly.
 "Service RAM Addresses"
Memory Dump
001
G3-1 Memory
Dump
Print out RAM data for the fax board.
 "Service RAM Addresses"
002
G3-2 Memory
Dump
Print out RAM data for the optional SG3
board.
003
G3-3 Memory
Dump
Print out RAM data for the optional SG3
board.
102
004 G4 Memory Dump Not used
G3-1 NCU Parameters
103
001 – 023 CC, 01 – 22
NCU parameter settings for the standard G3
board.  "NCU Parameters"
G3-2 NCU Parameters
104
001 – 023 CC, 01 – 22
NCU parameter settings for the optional G3
board.  "NCU Parameters"
G3-3 NCU Parameters
105
001 – 023 CC, 01 – 22
NCU parameter settings for the optional G3
board.  "NCU Parameters"
