Ricoh Aficio MP C3501

Service Tables
D393 60 SM
PSTN-3 Port Settings
001 Select Line
Select the line setting for the G3-3 line. If the
machine is installed on a PABX line, select
“PABX”, “PABX(GND)” or “PABX(FLASH)”.
002
PSTN Access
Number
Enter the PSTN access number for the G3-3
line.
003
Memory Lock
Disabled
Not used
105
004
Transmission
Disabled
If you turn this SP on, the machine does not
send any fax messages on the G3-3 line.
ISDN Port Settings
001 Select Line
002
PSTN Access
Number
106
003
Memory Lock
Disabled
106 004
Transmission
Disabled
Not used (Do not change the settings.)
IPFAX Port Settings
001 H323 Port Sets the H323 port number.
002 SIP Port Sets the SIP port number.
003 RAS Port Sets the RAS port number.
004 Gatekeeper port Sets the Gatekeeper port number.
005 T.38 Port Sets the T.38 port number.
006 SIP Server Port Sets the SIP port number.
107
007 IPFAX Protocol Select "H323" or "SIP".
