Ricoh Aficio MP C3501 Service Manual

Error Codes
D545 28 SM
Code Meaning Suggested Cause/Action
0-87
The control channel started
after an unsuccessful
primary channel.
 The receiving terminal restarted the control
channel because data reception in the primary
channel was not successful.
 This does not result in an error
communication.
0-88
The line was disconnected
because PPR was
transmitted/received 9
(default) times within the
same ECM frame.
 Try using a lower data rate at the start.
 Try adjusting the cable equalizer setting.
2-11
Only one V.21 connection
flag was received
 Replace the FCU.
2-12 Modem clock irregularity  Replace the FCU.
2-13 Modem initialization error
 Turn off the machine, then turn it back on.
 Update the modem ROM.
 Replace the FCU.
2-23
JBIG compression or
reconstruction error
 Turn off the machine, then turn it back on.
2-24 JBIG ASIC error  Turn off the machine, then turn it back on.
2-25
JBIG data reconstruction
error (BIH error)
 JBIG data error
 Check the sender’s JBIG function.
 Update the MBU ROM.
2-26
JBIG data reconstruction
error (Float marker error)
2-27
JBIG data reconstruction
error (End marker error)
2-28
JBIG data reconstruction
error (Timeout)
2-29
JBIG trailing edge maker
error
 FCU defective
 Check the destination device.

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
