Ricoh Aficio MP C3501 Service Manual

Error Codes
D545 38 SM
Code Meaning Suggested Cause/Action
15-42 Off Ramp Gateway Error
 The delivery destination address was
specified with Off Ramp Gateway OFF.
15-43 Address Format Error
 Format error in the address of the Off Ramp
Gateway.
15-44 Addresses Over
 The number of addresses for the Off Ramp
Gateway exceeded the limit of 30.
15-61
Attachment File Format
Error
 The attached file is not TIFF format.
15-62
TIFF File Compatibility
Error
Could not receive transmission due to:
 Resolution error
 Image of resolution greater than 200 dpi
without extended memory.
 Resolution is not supported.
 Page size error
 The page size was larger than A3.
 Compression error
 File was compressed with other than MH, MR,
or MMR.
15-63 TIFF Parameter Error
The TIFF file sent as the attachment could not be
received because the TIFF header is incorrect:
 The TIFF file attachment is a type not
supported.
 The TIFF file attachment is corrupted.
 Software error.
15-64 TIFF Decompression Error
The file received as an attachment caused the
TIFF decompression error:
 The TIFF format of the attachment is
corrupted.
 Software error.

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
