Service Tables
D545 58 SM
4.2.3 SP3-XXX (TEL LINE SETTINGS)
3
Mode No. Function
101
Service Station
001 Fax Number Enter the fax number of the service station.
002 Select Line Select the line type.
102
Serial Number
000 Enter the fax unit’s serial number.
103
PSTN-1 Port Settings
001 Select Line
Select the line type setting for the G3-1 line. If
the machine is installed on a PABX line, select
“PABX”, “PABX(GND)” or “PABX(FLASH)”.
002
PSTN Access
Number
Enter the PSTN access number for the
G3-1 line.
003
Memory Lock
Disabled
Not used
104
PSTN-2 Port Settings
001 Select Line
Select the line setting for the G3-2 line. If the
machine is installed on a PABX line, select
“PABX”, “PABX(GND)” or “PABX(FLASH)”.
002
PSTN Access
Number
Enter the PSTN access number for the G3-2
line.
003
Memory Lock
Disabled
Not used
004
Transmission
Disabled
If you turn this SP on, the machine does not
send any fax messages on the G3-2 line.
