Bit Switches
SM 77 D545
Fax option
Type C5501
D545
System Switch 11 (SP No. 1-101-018)
No Function Comments
0
TTI printing position
0: Superimposed on the page
data
1: Printed before the data
leading edge
Change this bit to 1 if the TTI overprints
information that the customer considers to be
important (G3 transmissions).
NOTE: If "1" is selected, it is possible that sent
data is printed on two sheets of paper.
1
TSI (G3) printing position
0: Superimposed on the page
data
1: Printed before the data
leading edge
Change this bit to 1 if the TSI (G3) overprints
information that the customer considers to be
important.
2 Not used Do not change the factory settings.
3
TTI used for broadcasting
0: The TTIs selected for each
Quick/Speed dial are used
1: The same TTI is used for all
destinations
1: The TTI (TTI_1 or TTI_2) which is selected
for all destinations during broadcasting.
4-7 Not used Do not change the factory settings.
System Switch 12 (SP No. 1-101-019)
No Function Comments
0-7
TTI printing position in the main
scan direction
TTI: 08 to 92 (BCD) mm
Input even numbers only.
This setting determines the print start position
for the TTI from the left edge of the paper. If the
TTI is moved too far to the right, it may
overwrite the file number which is on the top
right of the page. On an A4 page, if the TTI is
moved over by more than 50 mm, it may
overwrite the page number.
