Bit Switches
D545 102 SM
ID code of the local terminal. This
function is only available in
NSF/NSS mode.
Communication Switch 01 (SP No. 1-104-002)
No Function Comments
0
ECM
0: Off 1: On
If this bit is set to 0, ECM is switched off for all
communications.
In addition, V.8 protocol and JBIG compression
are switched off automatically.
1 Not used Do not change the setting.
2-3
Wrong connection prevention
method
(0,1): The machine will disconnect the line
without sending a fax message, if the last 8
digits of the received CSI do not match the last
8 digits of the dialed telephone number. This
does not work when manually dialed.
(1,0): The same as above, except that only the
last 4 digits are compared.
(1,1): The machine will disconnect the line
without sending a fax message, if the other end
does not identify itself with an RTI or CSI.
(0,0): Nothing is checked; transmission will
always go ahead.
This function does not work when
dialing is done from the external
telephone.
Bit 3 Bit 2 Setting
0 0 None
0 1 8 digit CSI
1 0 4 digit CSI
1 1 CSI/RTI
4-5 Not used Do not change the setting.
