Ricoh Aficio MP C3501 Service Manual

Duplex Unit
D086/D087 4-146 SM
9. Hold the right door, and then release the wire [A] (
x 1).
 Keep holding the right door before removing the right door completely.
Otherwise, the right door can fall down and injure you.
10. Press the projection [B] to pull the right door shaft into the unit, and then remove the
duplex unit [C] (
x 1, x 1, x 4, ground cable x 1).

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
