SM 5-57 D086/D087
System
Maintenance
2181 [Line Position Adj. Result]
Displays the values for each correction.
"Paper Int. Mag: Subdot" indicates the magnification correction value
between two sheets of paper.
"Mag.Cor. Subdot" indicates the magnification correction value.
"M. Scan Erro." indicates the shift correction value in the main scan
direction.
"S. Scan Erro." Indicates the shift correction value in the sub scan
direction.
"M. Cor.: Dot" indicates the dot correction value in the main scan direction.
"M. Cor.: Subdot" indicates the sub dot correction value in the main scan
direction.
Bk: Black, M: Magenta, C: Cyan, Y: Yellow
001 Paper Int. Mag: Subdot: Bk *ENG
[–32768 to 32767 / 0 / 1 pulse/step]
002 Mag.Cor. Subdot: Bk *ENG
[–32768 to 32767 / 0 / 1 pulse/step]
003 Skew: M *ENG
[–5000 to 5000 / 0 / 0.001 um/step]
005 M. Scan Erro.: Left: M *ENG
[–5000 to 5000 / 0 / 0.001 um/step]
006 M. Scan Erro.: Center: M *ENG
007 M. Scan Erro.: Right: M *ENG
008 S. Scan Erro.: Left: M *ENG
009 S. Scan Erro.: Center: M *ENG
010 S. Scan Erro.: Right: M *ENG
011 M. Cor.: Dot: M *ENG
[–512 to 511 / 0 / 1 dot/step]
012 M. Cor.: Subdot: M *ENG
[–15 to 15 / 0 / 1 pulse/step]
013 Paper Int. Mag: Subdot: M *ENG [–32768 to 32767 / 0 / 1 pulse/step]
