Ricoh Aficio MP C3501 Service Manual

Product Overview
SM 1-5 D086/D087
Product
Information
7. Paper feed clutch Switches the drive power between tray 1 and tray 2.
8. Paper feed motor: Drives the paper feed mechanisms (tray 1/tray 2).
9. By-pass feed clutch:
Turns on/off the drive power to the by-pass pick-up,
feed and separation rollers.
10. Registration motor: Drives the registration roller.
11. By-pass/duplex feed motor:
Drives the by-pass pick-up, feed and separation roller,
and duplex transport rollers.
12. Paper transfer contact
motor:
Moves the paper transfer roller in contact with the
image transfer belt.
13. ITB drive motor: Drives the image transfer belt unit.
14. Duplex inverter motor
Drives the duplex inverter rollers and duplex transport
rollers.
15. Fusing/paper exit motor: Drives the fusing unit and paper exit section.

Ricoh Aficio MP C3501 Specifications

General

Print Technology	Laser
Print Speed (Color)	35 ppm
Print Speed (Monochrome)	35 ppm
Maximum Print Resolution	1200 x 1200 dpi
Standard Paper Capacity	1, 200 sheets
Maximum Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Maximum Scan Resolution	600 dpi
Copier Resolution	600 dpi
Fax Capability	Optional
Memory (Maximum)	1.5 GB
Network Connectivity	Ethernet
Connectivity	USB 2.0, Ethernet 10/100Base-TX
Functions	Print, Copy, Scan
Hard Disk Drive	160 GB
Scan Speed	50 ipm
Operating System Compatibility	Windows, Mac, Linux
