Main SP Tables-2
D086/D087 5-62 SM
2185
[Main Scan Length Detection Disp.]
Displays/adjusts the target value for the main scan magnification correction of
the line position adjustment.
After replacing the laser optics housing unit, input the standard value for Bk
provided with the new unit. For details, see "Laser Optics Housing Unit" in the
"Replacement Adjustment" section. It is not necessary to input the values for
the other colors; these are automatically adjusted after doing the line position
adjustment.
001 Bk *ENG
[0 to 266667 / 249449 / 1 sub-dot/step]
002 M *ENG
003 C *ENG
004 Y *ENG
2193 [MUSIC Condition Set] Line Position Adjustment: Condition Setting
001
Auto Execution *ENG
[0 or 1 / 1 / 1 ]
0: OFF, 1: ON
Enables/disables the automatic line position adjustment
002
Page: Job End: BW+FC *ENG
[0 to 999 / 500 / 1 page/step]
Adjusts the threshold of the line position adjustment for BW and color printing
mode after job end.
003
Page: Job End: FC *ENG
[0 to 999 / 200 / 1 page/step]
Adjusts the threshold of the line position adjustment for color printing mode
after job end.
