Main SP Tables-2
SM 5-81 D086/D087
System
Maintenance
2424
[Plain: Switch Timing: Trail. Edge]
Adjusts the bias/voltage switch timing of the paper transfer roller/discharge
plate at the paper trailing edge between the erase margin area and the image
area.
Plain: High speed, Thick 1: Middle speed, Thick 2&Fine: Low speed
001 Paper Transfer: Plain: 1st Side *ENG
[0 to 50 / 0 / 2 mm/step]
002 Paper Transfer: Plain: 2nd Side *ENG
003 Paper Transfer: 1200: 1st Side *ENG
004 Paper Transfer: 1200: 2nd side *ENG
005 Separation DC: Plain: 1st Side *ENG
006 Separation DC: Plain: 2nd Side *ENG
007 Separation DC: 1200: 1st Side *ENG
008 Separation DC: 1200: 2nd Side *ENG
2451
[Thin: Bias]
Adjusts the DC voltage of the discharge plate for thin paper.
Plain: High speed, Thick 1: Middle speed, Thick 2&Fine: Low speed
001 Separation DC: Plain: 1st Side *ENG
[0 to 4000 / 2000 / 10
–V/step]
003 Separation DC: 1200: 1st Side *ENG
2453
[Thin: Bias: BW]
Adjusts the current for the paper transfer roller for thin paper in black-and-white
mode.
Plain: High speed, Thick 1: Middle speed, Thick 2&Fine: Low speed
001 Paper Transfer: Plain: 1st Side *ENG
[0 to 250 / 22 / 1 –
A /step]
003 Paper Transfer: 1200: 1st Side *ENG
[0 to 250 / 11 / 1 –
A /step]
