Safran CORTEX Series - Digital Outputs; Figure 33: BER Measurement Methods: Tested Ambiguities and GUI Display

HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 109
REGISTRY
SELECTION
4.2.9.2.3
QPSK
OQPSK
QPSK & OQPSK
+ SINGLE VITERBI
BPSK
UQPSK AQPSK
8PSK
0
Method 1:
IQ,/IQ,I/Q,/I/Q,
QI,/QI, Q/I,/Q/I
GUI: 1 BER value
(I,Q average)
Method 1:
IQ,/I/Q
(IQ merged before
Viterbi decoding)
GUI: 1 BER value
Method 1:
I,/I
GUI: 1 BER value
Method 1:
I,/I, on I
Q,/Q on Q
GUI: 2 BER values
(BER I & BER Q)
Method 1:
8 phase
ambiguities
GUI: 1 BER value
(averaged BER)
1
Method 1:
IQ,/IQ,I/Q,/I/Q,
QI,/QI, Q/I,/Q/I
GUI: 2 BER values
(BER I & BER Q)
2
Method 2:
GUI: 1 BER value
(BER IQ)
Method 2:
GUI: 1 BER value
Method 2:
GUI: 1 BER value
(BER I)
Method 2:
GUI: 2 BER values
(BER I &BER Q)
Method 2:
GUI: 1 BER value
(averaged BER)
Figure 33: BER Measurement Methods: Tested ambiguities and GUI display
Digital Outputs 3.3.9
Digital outputs characteristics can be configured:
 Clock polarity: normal or inverted.
 Data (I/Q) polarity: normal or inverted.
 Data swap: Normal I & Q, I inverted & Q, I & Q inverted, I inverted & Q inverted
+ Swap: Q & I, Q inverted & I, Q & I inverted, Q inverted & I inverted
 Output mode: Normal or split (separate I & Q output) or I/Q merged or CADU output (refer to
the Hardware Description chapter)
