4G / XXL test modulator menus equivalence 4.2.7
Here is a table which provides test modulator menu number equivalence with previous generation of
Cortex HDR.
XXL Menu
4G Menu
Description
Number
Number
Comment
Default
1
3
UQPSK
2
12
High Speed
3
1
Byte out
4
4
Parallel DGU
5
13
FIR 4SR
6
3
Doppler
7
3
DVBS2
8
2
GOES-R
9
-
Not supported. Mission specific.
CSO/Pleiades
10
4
Myriad
11
-
Not supported. Mission specific.
AIT
12
-
Not supported. Mission specific.
AIT
13
9
Astra
14
-
Not supported. Mission specific.
FIR 2SR
15
3
AIT
16
-
Not supported. Mission specific.
AIT
17
-
Not supported. Mission specific.
AIT
18
-
Not supported. Mission specific.
AIT
19
-
Not supported. Mission specific.
LDPC 1/2
20
5
AIT
21
-
Not supported. Mission specific.
AIT
22
-
Not supported. Mission specific.
AIT
23
-
Not supported. Mission specific.
Pi/4-DQPSK
24
-
Not supported.
