2 HARDWARE DESCRIPTION
CORTEX HDR INTEGRATION 2.1
Hardware Configuration 2.1.1
In its minimum hardware configuration, the HDR 4G unit consists in:
- one 4U-high PC-compatible workstation
- one demodulator module with its I/O interfaces (LVDS-ECL interfaces)
Depending on the delivered configuration, optional hardware parts can be added to the unit and consist
in:
- test modulator board
- custom I/O interface board
- Dual port 10 Gigabit RJ45 copper or LC fiber-optic connectors (configuration dependent)
- System storage: raid0 raid6 4 or 12 disk from 1Terra or 2Terra byte disk
The position of the boards inside the chassis must not be changed. A sticker at the rear panel of the
equipment shows how the boards must be mounted in the chassis. Do not change this setting.
PC-compatible Workstation 2.1.2
The PC-compatible workstation cabling is described in Annex 4.
