HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 280
 5/6(conv.1) 5/6 Viterbi (convention 1)
 5/6(conv.2) 5/6 Viterbi (convention 2)
 6/7 6/7 Viterbi
 7/8 (conv.1) 7/8 Viterbi (convention 1)
 7/8 (conv.2) 7/8 Viterbi (convention 2)
 1/4 Esrin 1/4 Viterbi (ESA / ESRIN type)
Monitoring 4.5.4.5.2
Upper Banner 4.5.4.5.2.1
See section 4.5.4.1.2.1 .
Other Status & Alarms 4.5.4.5.2.2
 For TCM configuration:
BER
TCM Bit Error Rate (must be 0 if no error detected). Important: the BER is
analyzed at the bit synchronizer output (before TCM decoding)
TCM DECODER
TCM decoder status:
 Locked
 Unlocked
 Disabled
 For single Viterbi configuration:
BER
Viterbi Bit Error Rate (must be 0 if no error detected). Important: the BER is
analyzed at the bit synchronizer output (before Viterbi decoding)
VITERBI DECODER
Viterbi decoder status:
 Locked
 Unlocked
 Disabled
