Safran CORTEX Series - Table 11: Counter Capacity and Resolution at 720 Mhz

HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 113
Table 11: Counter capacity and resolution at 720MHz
Truncature
(N)
Phase
resolution
in deg
64-bits phase
revolution time
Doppler
resolution
over 1s in Hz
26
5.6E+00
12 y 253 d 7 h 59 m 26 s
1.6E-02
25
2.8E+00
6 y 126 d 15 h 59 m 43 s
7.8E-03
24
1.4E+00
3 y 63 d 7 h 59 m 51 s
3.9E-03
23
7.0E-01
1 y 214 d 3 h 59 m 55 s
2.0E-03
22
3.5E-01
289 d 13 h 59 m 57 s
9.8E-04
21
1.8E-01
144 d 18 h 59 m 58 s
4.9E-04
20
8.8E-02
72 d 9 h 29 m 59 s
2.4E-04
19
4.4E-02
36 d 4 h 44 m 59 s
1.2E-04
18
2.2E-02
18 d 2 h 22 m 29 s
6.1E-05
17
1.1E-02
9 d 1 h 11 m 14 s
3.1E-05
16
5.5E-03
4 d 12 h 35 m 37 s
1.5E-05
15
2.7E-03
2 d 6 h 17 m 48 s
7.6E-06
14
1.4E-03
1 d 3 h 8 m 54 s
3.8E-06
13
6.9E-04
13 h 34 m 27 s
1.9E-06
12
3.4E-04
6 h 47 m 13 s
9.5E-07
11
1.7E-04
3 h 23 m 36 s
4.8E-07
10
8.6E-05
1 h 41 m 48 s
2.4E-07
9
4.3E-05
50 m 54 s
1.2E-07
8
2.1E-05
25 m 27 s
6.0E-08
7
1.1E-05
12 m 43 s
3.0E-08
6
5.4E-06
6 m 21 s
1.5E-08
5
2.7E-06
3 m 10 s
7.5E-09
4
1.3E-06
1 m 35 s
3.7E-09
3
6.7E-07
47.7 s
1.9E-09
2
3.4E-07
23.8 s
9.3E-10
1
1.7E-07
11.9 s
4.7E-10
0
8.4E-08
5.9 s
2.3E-10
Default
registry value
for N
