HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Here is the table of connector allocation depending on the data scheme, for differential ECL:
Table 16: connectors allocation, Differential ECL
IQZ and X bits are always read from left to right is the constellation mappings. Here is an example of
IQZ mapping in 8PSK:
Figure 71: IQZ mapping example
