HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Example of a configuration text file for the logging of 4 parameters of the demodulator unit 1:
* -----------------------------------------------------------------------------
* Example of a Logging Configuration File
*
* The lines beginning by * or # are comments
*
* The first line is mandatory and gives the sampling period of the parameters recording *
(minimum: * 100 ms). The value “1” is kept for the coherence of the file.
*
* The other lines are the logging elements and defined as:
* the Componant table number (hexa) followed by the offset of the parameter in the table *
(decimal)
*
* -----------------------------------------------------------------------------
* Sampling period - Mini = 100ms
1000 1
* Cortex Station - Start/Stop storage status
201 28
* DEMOD A – Carrier Offset
3010 40
* DEMOD A – IF Level
3010 41
* DEMOD A – Eb/No
3010 43
* DEMOD A – PLL Status
3010 42
* -----------------------------------------------------------------------------
System Logging 3.8.3
This logging traces events on Cortex HDR. A verbosity level is defined in registry, enabling to trace
alarms (value 0), HDR state changes (1: default install value).
There is a daily log file: when Signal Processing software detects a day change on an event log,
current file is closed and a new file opened.
N.B.: for this logging Windows time is used.
Generated files have XML format. They are located in:
D:\ZDS\DATA\HDR\log\system
An automatic erase process exists on logging folder: D:\ZDS\DATA\HDR\log\system
A maximum size is defined in registry (HKEY_LOCAL_MACHINE\SOFTWARE\IN-
SNEC\CrtxHdr\SetDefault\Preferences\Global\PurgeSize_systLog). By default, install value is set to
100MBytes.
When this size is reached, oldest files are erased.
