Operating @ 1.2 GHz +/-300MHz IF input):
Maximum actual symbol rate
500 Msps
Maximum Bit rate in BPSK mode
500 Mbps
Maximum Bit rate in QPSK modes
1000 Mbps
Maximum bit rate in 8PSK mode
1500 Mbps
Maximum bit rate in 16QAM / 16APSK, 32APSK,
64APSK mode
2000 Mbps
Operating @ 2.4 GHz IF input:
Maximum actual symbol rate
1.2 Gsps
Maximum Bit rate in BPSK mode
1.2 Gbps
Maximum Bit rate in QPSK modes
2.4 Gbps
Maximum bit rate in 8PSK mode
3.6 Gbps
Maximum bit rate in 16QAM / 16APSK, 32APSK,
64APSK mode
4.8 Gbps
Synchronization threshold  1dB (Eb/No) in QPSK,  3,5dB (Eb/No) in 8PSK
Acquisition time  0.25 second
Doppler measurement Yes
Doppler rate  10 kHz/s
IF level measurement accuracy  2 dB
Cable Equalizer (note 1) Yes. Amplitude equalization: 0 to 12 dB between 570 & 870 MHz
Implementation loss 1.6.1.3
Implementation losses:
 are given in dB to theoretical value;
 take into account all part HDR 4G part the unit filter/demodulator/decoding…;
 are given with actual BER measurement using a SDSY Test modulator assuming
no implementation loss @ SDSY test modulator.
<1dB at @ 90% of max value of Bit Rate value
<0,5dB @ 50% of max value of Bit Rate value
<0,3dB @ 25% of max value of Bit Rate value
