Demodulation 1.6.1.2
Demodulation (notes 1) BSPK, QPSK, OQPSK (SQPSK)
UQPSK (AQPSK, AUQPSK, AUSQPSK), 8PSK, GMSK, 16QAM,
16APSK, 32APSK, 64APSK, 128APSK, 256APSK
SOQPSK (MIL standard filter, IRIG TG filter, CCSDS A-type or B-type
filters)
Bit rates (notes 1, 2 & 3)
Operating @ 1.25 GHz IF input:
Maximum actual symbol rate
1.6 Gsps
Maximum Bit rate in BPSK mode
1.6 Gbps
Maximum Bit rate in QPSK modes
3.2 Gbps
Maximum bit rate in 8PSK mode
4.8 Gbps
Maximum bit rate in 16QAM / 16APSK, 32APSK,
64APSK mode
6.4 Gbps
Operating @ 720 MHz IF input:
Maximum actual symbol rate per channel
320 Msps
Maximum Bit rate in BPSK mode per channel
320 Mbps
Maximum Bit rate in QPSK modes per channel
640 Mbps
Maximum bit rate in 8PSK mode per channel
960 Mbps
Maximum bit rate in 16QAM/16APSK mode per channel
1280 Mbps
