Monitoring 4.5.7.1.2
Status & alarms in this window are described in DRG.
Indicates which mode of storage is active example: FTP CCSDS (standard)
CORTEX HDR mode: Configuration or Acquisition.
Important: in the Acquisition mode, the Data Processing Unit(s) cannot be re-
configured. The maximum number of TM Packets per TM file (Data Recording
Unit) cannot be changed. Data Recording Global (DRG) parameters cannot be
changed.
Click on for changing the mode. Switching to Configuration mode is
impossible if a TM Client is connected to the telemetry port (3075) or if telemetry
storage is in progress. Switching to Acquisition mode is impossible if the requested
configuration is incorrect.
In configuration mode, a periodical auto-test is performed on the defined partitions.
This test consists in writing a file in the directories and trying to read it. The result is
OK or Non OK as soon as one partition is in error.
Status of the FTP directories.
General status of the actual configuration.
Disk partitioning information and status.
