M&C Session. MCS Documents Management 4.3.4
Close the Active M&C Session 4.3.4.1
 Click on FILE → CLOSE. If required, save the active MCS Table to the disk.
Open an M&C session with a CORTEX 4.3.4.2
 Click on FILE → NEW. An empty MCS Login window appears on the screen. The MCS creates
an empty MCS Table in RAM.
 Enter the IP address or name of the CORTEX unit and click on (or click on CONNECT).
Once the monitoring connection is established, the MCS starts monitoring the unit and initializes
the contents of the MCS Table (IP address or name of the unit included). The MCS control
status is set to , indicating that the contents of the MCS Table strictly matches the
configuration of the unit. The MCS Table is automatically updated every time the Operator
modifies the setting of the unit from the MCS on which the M&C session has been started (the
MCS control status remains to ).
 The MCS control status automatically turns to if any remote Monitoring & Control
system modifies the configuration of the unit.
 For saving the MCS Table to an MCS Document on the disk, see next section. Note: multiple
M&C sessions can be simultaneously started from the MCS.
Save the CORTEX Configuration to an MCS Document on the Disk 4.3.4.3
 Verify that the MCS control status is set to . If it is set to click first on
 If the MCS Table has never been saved to the disk, click on FILE → SAVE or FILE → SAVE AS
and either confirm the name proposed in the dialog box or enter another name.
 If the MCS Table has already been previously saved to the disk, click on FILE → SAVE to save
it again to the same MCS Document or click on FILE → SAVE AS to save it to another new or
existing MCS Document.
Reconfigure the CORTEX from an Existing MCS Document 4.3.4.4
 Close the active M&C session (click on FILE → CLOSE).
 Click on FILE → OPEN and select an MCS Document in the proposed list. The selected MCS
Document is copied to an MCS Table in RAM.
 Click on to reconfigure the CORTEX from the new MCS Table. The MCS control status is
changed to , indicating that the unit has been successfully reconfigured.
