Operating System and files architecture 4.4
Introduction 4.4.1
From the release E9R0, the Cortex HRD units come with Windows 7 embedded operating system in
place of the former Windows 2000 and Windows XP.
Depending on the Operating System, the Cortex HDR software and files can be found in different
directories. The paths of these different directories are given in the following paragraphs.
To improve security, with Windows 7, the Cortex user does not have access to C drive anymore. The
configurations files have been moved to D drive.
Files Architecture 4.4.2
Files associated with Monitoring & Control Software 4.4.2.1
FILE
WINDOWS 7
WINDOWS 2000 AND XPE
MCS Application
C:\Program Files\ZDS\CrtxMcs
C:\Program Files\IN-SNEC\CrtxMcs
MCS Files
D:\ZDS\Data\HDR\CrtxMcs\DefaultConfig
D:\ZDS\Data\HDR\CrtxMcs\DefaultConfig_ref
(and subdirectories)
C:\Program Files\IN-SNEC\CrtxMcs\DefaultConfig
C:\Program Files\IN-SNEC\CrtxMcs\DefaultConfig_ref
(and subdirectories)
User’s MCS Files
D:\ZDS\Data\HDR\CrtxMcs\UserConfig
C:\Program Files\IN-SNEC\CrtxMcs\UserConfig
Files associated with the Signal Processing Software 4.4.2.2
FILE
WINDOWS 7
WINDOWS 2000 AND XPE
SPS Application
C:\Program Files\ZDS\crtxnt
C:\Program Files\IN-SNEC\crtxnt
Menu List
D:\ZDS\Data\HDR\crtxnt\Menus
C:\Program Files\IN-SNEC\crtxnt\Menus
Menu CTX Files
D:\ZDS\Data\HDR\crtxnt\Menus\CTX
D:\ZDS\Data\HDR\crtxnt\Menus\CTX_ref
C:\Program Files\IN-SNEC\crtxnt\Menus\CTX
C:\Program Files\IN-SNEC\crtxnt\Menus\CTX_ref
User’s CTX Files
D:\ZDS\Data\HDR\crtxnt\NameTable.txt
D:\ZDS\Data\HDR\crtxnt\SatCnfXX.ctx
(with XX = 01 to 10)
C:\Program Files\IN-SNEC\crtxnt\NameTable.txt
C:\Program Files\IN-SNEC\crtxnt\SatCnfXX.ctx
(XX = 01 to 10)
BER Files
D:\ZDS\Data\HDR\crtxnt\BER
C:\Program Files\IN-SNEC\crtxnt\BER
VCM Files
D:\ZDS\Data\HDR\crtxnt\VCM
C:\Program Files\IN-SNEC\crtxnt\VCM
DVB S2 & SCCC
Gamma Files
D:\ZDS\Data\HDR\crtxnt\VCM\gamma
C:\Program Files\IN-SNEC\crtxnt\VCM\gamma
FIR Files
D:\ZDS\Data\HDR\crtxnt\fir
C:\Program Files\IN-SNEC\crtxnt\fir
Test Definition
Files
D:\ZDS\Data\HDR\crtxnt\TEST
C:\Program Files\IN-SNEC\crtxnt\TEST
Script Files
D:\ZDS\Data\HDR\crtxnt\Qual
D:\ZDS\Data\HDR\crtxnt\Scripts
(and subdirectories)
C:\Program Files\IN-SNEC\crtxnt\Qual
C:\Program Files\IN-SNEC\crtxnt\Scripts
(and subdirectories)
Storage
Definition Files
D:\ZDS\Data\HDR\Storage
D:\ZDS\Data\HDR\Storage
FTP Sorting Files
D:\ZDS\Data\HDR\ftp
(and subdirectories)
C:\Program Files\IN-SNEC\ftp
(and subdirectories)
CFDP Sorting
Files
D:\ZDS\Data\HDR\cfdp
(and subdirectories)
C:\Program Files\IN-SNEC\cfdp
(and subdirectories)
Log Files
D:\ZDS\Data\HDR\log
C:\Program Files\IN-SNEC\log
STI Logging Files
D:\ZDS\Data\HDR\log\param_surv
C:\Program Files\IN-SNEC\log\param_surv
