HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
The number of the selected file appears inside the “Selected” box. The status “Last Conf” is equivalent
to the OK/Differ status of GUI.
MCS File System Architecture 4.3.11
IN-SNEC MCS software can be found in the following directories. Do not move or modify these
directories:
C:\Program Files\In-snec
Or
D:\ZDS\Data\HDR
Root directory
Upgrade.txt: list of s/w packages (ID + version)
Monitoring & Control Software
Graphical User Interface
MCS files (read only
reference files)
MCS files (read only
reference files)
MCS System Parameters in Registry 4.3.12
MCS system parameters are high-level parameters in the registry. Changing them requires restarting
the CORTEX MCS application software:
Monitoring 4.3.12.1
Monitoring Rate 4.3.12.1.1
To change the time interval between two consecutive monitoring cycles by the MCS software:
Registry path: HKEY_LOCAL_MACHINE / SOFTWARE\In-Snec\CrtxMcs\Tcp
Keyword: Monitoring
Setting:
500D. Default: 500. Expressed in ms
Example: for a monitoring request every four seconds, enter FA0 (in hexadecimal) or 4000 (in decimal).
Minimum value: 1F4
H
= 500
D
(monitor the equipment twice per second).
MCS Auto-Connect 4.3.12.2
The following registry keys enables to force the MCS to regularly attempt to reconnect to the monitoring
port of the CORTEX. The auto-connect mode is particularly useful on multi-menu CORTEX.
Auto Connect ON/OFF 4.3.12.2.1
Registry path: HKEY_LOCAL_MACHINE / SOFTWARE\In-Snec\CrtxMcs\Tcp
Keyword: AutoReconnect
Setting: 0: auto-connect mode disabled. 1: auto-connect mode enabled
