Safran CORTEX Series - Table 12: Counter Capacity and Resolution at 1.2 Ghz

HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 114
Truncature
(N)
Phase
resolution
in deg
64-bits Phase
revolution time
Doppler
resolution
over 1s (in Hz)
26
5.6E+00
7 y 241 d 4 h 51 m 50 s
1.6E-02
25
2.8E+00
3 y 303 d 2 h 25 m 55 s
7.8E-03
24
1.4E+00
1 y 334 d 1 h 12 m 57 s
3.9E-03
23
7.0E-01
349 d 12 h 36 m 28 s
2.0E-03
22
3.5E-01
174 d 18 h 18 m 14 s
9.8E-04
21
1.8E-01
87 d 9 h 9 m 7 s
4.9E-04
20
8.8E-02
43 d 16 h 34 m 33 s
2.4E-04
19
4.4E-02
21 d 20 h 17 m 16 s
1.2E-04
18
2.2E-02
10 d 22 h 8 m 38 s
6.1E-05
17
1.1E-02
5 d 11 h 4 m 19 s
3.1E-05
16
5.5E-03
2 d 17 h 32 m 9 s
1.5E-05
15
2.7E-03
1 d 8 h 46 m 4 s
7.6E-06
14
1.4E-03
16 h 23 m 2 s
3.8E-06
13
6.9E-04
8 h 11 m 31 s
1.9E-06
12
3.4E-04
4 h 5 m 45 s
9.5E-07
11
1.7E-04
2 h 2 m 52 s
4.8E-07
10
8.6E-05
1 h 1 m 26 s
2.4E-07
9
4.3E-05
30 m 43 s
1.2E-07
8
2.1E-05
15 m 21 s
6.0E-08
7
1.1E-05
7 m 40 s
3.0E-08
6
5.4E-06
3 m 50 s
1.5E-08
5
2.7E-06
1 m 55 s
7.5E-09
4
1.3E-06
57.6 s
3.7E-09
3
6.7E-07
28.8 s
1.9E-09
2
3.4E-07
14.4 s
9.3E-10
1
1.7E-07
7.2 s
4.7E-10
0
8.4E-08
3.6s
2.3E-10
Table 12: Counter capacity and resolution at 1.2GHz
Default
registry value
for N
