Safran CORTEX Series - LDPC Status; CRC Status

HIGH DATA RATE RECEIVER
HDR-4G+ USER’S MANUAL
Ref. DTU 100782
Is.Rev 3.5
Date: June 1, 2021
© Safran Data Systems – IMP000074 e14r1
This document is the property of Safran Data Systems.
It cannot be duplicated or distributed without expressed written consent.
Page 295
LDPC Status 4.5.5.1.2.4
CORRECTED ERRORS
Number of symbols corrected by the LDPC decoder (average value computed
over a one-second period of time).
GOOD FRAMES
Number of good transfer frames received from the LDPC decoder. Reset to 0
when the Frame Synchronizer or the LDPC decoder is set to OFF or by clicking
on in the upper tool bar (the DPU window must be active).
BAD FRAMES
Number of bad transfer frames received from the LDPC decoder. Reset to 0 when
the Frame Synchronizer or the LDPC decoder is set to OFF or by clicking on
in the upper tool bar (the DPU window must be active).
BIT ERROR RATE ON
INPUT DATA
Estimation of the BER at the input of the LDPC decoding. Reset to 0 when the
Frame Synchronizer or the LPC decoder is set to OFF or by clicking on in
the upper tool bar (the DPU window must be active).
BIT ERROR RATE ON
OUTPUT DATA
Estimation of the BER at the output of the LDPC decoding. Reset to 0 when the
Frame Synchronizer or the LDPC decoder is set to OFF or by clicking on in
the upper tool bar (the DPU window must be active).
CRC Status 4.5.5.1.2.5
GOOD FRAMES
Number of good transfer frames received from the CRC decoder. Reset to 0 when
the Frame Synchronizer or the Reed Solomon decoder is set to OFF or by clicking
on in the upper tool bar (the DPU window must be active).
BAD FRAMES
Number of bad transfer frames received from the CRC decoder. Reset to 0 when
the Frame Synchronizer or the Reed Solomon decoder is set to OFF or by clicking
on in the upper tool bar (the DPU window must be active).
