PHASE ROTATION
Select CCSDS (Counter Clock Wise) or Inverted (Clock Wise)
RANDOMIZER
Type of Auto synchronized Randomizer
 Disable
 WorldView
 CCITT V.35
 IntelSat V.35
I/Q SHIFT
Allows adjusting the I/Q offset in OQPSK mode for test purposes
Enter any value from +0.5 to -0.5 (in symbol). Select 0 for optimal OQPSK (half-
symbol offset).
This parameter is not yet available
VITERBI ENCODING
VITERBI ENCODING Q
Convolutional encoder setting for the I and/or Q Channel
 OFF: disabled
 G1 – G2 Inv: G2 inverted (G1 first)
 G1 – G2: G2 normal (G1 first)
 G2 Inv – G1: G2 inverted (G2 first)
 G2 – G1: G2 normal (G2 first)
Refer to the CCSDS recommendations for “G2 normal/inverted” definition
VITERBI SCHEME
 Single – 1 I+Q: Single encoder common to I & Q Channels
 Dual – 1I / 1Q: Separate encoders for I & Q Channels
 XI / XQ: Separate encoders for I & Q Channels. X is the number of
parallel encoders
VITERBI PUNCTURING
VITERBI PUNCTURING Q
Puncturing setting for Viterbi encoding
 OFF
 ON (registry): defined in registry
 a/b (Conv. X): Puncturing a/b (convention 1 or 2)
 1/4 ESRIN
TCM ENCODER
TCM encoder for 8PSK modulation mode:
 OFF: disabled
 2.XX/3: 4D-TCM rate 2.XX/3
 DSNG 5/6
FILTER
Modulation Filter:
 Off
 RC
 RRC
 GMSK
 Custom
FILTER FILE
Only when Custom Filter is selected
ROLL-OFF
Roll-Off factor for the RC/RRC filter
BT
BT factor for the GMSK filter
SAMPLING
XSR: Enable the high rate filter at F
e
equal X times the Symbol Rate
