Machining the workpiece
4.3 Executing a trail program run
Turning
Operating Manual, 03/2013, 6FC5398-8CP40-3BA1
119
4. Place the cursor on the desired program.
5. Press the "Select" softkey.
The program is selected.
When the program has been successfully selected, an automatic
changeover to the "Machine" operating area occurs.
4.3 Executing a trail program run
When testing a program, the system can interrupt the machining of the workpiece after each
program block, which triggers a movement or auxiliary function on the machine. In this way,
you can control the machining result block-by-block during the initial execution of a program
on the machine.
Note
Settings for the automatic mode
Rapid traverse reduction and dry run feed rate are available to run-in or to test a program.
Move by single block
In "Program control" you may select from among several types of block processing:
SB mode Scope
SB1 Single block,
coarse
The machining stops after every machine block (except for cycles)
SB2 Data block The machining stops after every block, i.e. also for data blocks (except for
cycles)
SB3 Single block,
fine
The machining stops after every machine block (also in cycles)
Precondition
A program must be selected for execution in "AUTO" or "MDA" mode.
Procedure
1. Press the "Prog. ctrl." softkey and select the desired variant in the "SBL"
field.
2. Press the <SINGLE BLOCK> key.
